Single Form 2440x1220x15 mm
SKU: FFP02002440122015
15mm T · 1220×2440 mm · ~25.45 kg/sheet · ρ ≈ 570 kg/m³
Single Form by VINAWOOD is the cost-effective formwork materials for projects that require fewer usage times and faster construction timeline. One side is coated with waterproofing phenolic layer while the other side is core veneer. This construction reduces cost while maintaining key characteristics of this plywood. The main market for this formwork materials is currently Malaysia and Singapore.
Specifications
Basic Specifications
- Grade
- Mixed GradePanel constructed with a combination of different veneer grades across core layers. Cost-effective option for formwork and industrial applications where consistent grading throughout is not required.Panel constructed with a combination of different veneer grades across core layers. Cost-effective option for formwork and industrial applications where consistent grading throughout is not required.
- Color
- Dark BrownDeep brown coloring characteristic of phenolic resin-treated or film-faced surfaces on formwork and industrial plywood panels.Deep brown coloring characteristic of phenolic resin-treated or film-faced surfaces on formwork and industrial plywood panels.
- Application
- FormworkConcrete forming and shuttering panels engineered to withstand repeated pours, chemical exposure, and high moisture on construction sites. Formwork plywood features overlay surfaces (phenolic, HDO, or MDO) for smooth concrete finishes and extended reuse life.Concrete forming and shuttering panels engineered to withstand repeated pours, chemical exposure, and high moisture on construction sites. Formwork plywood features overlay surfaces (phenolic, HDO, or MDO) for smooth concrete finishes and extended reuse life.
- Back
- Sanded core or VeneerFlexible back finish available as either sanded core or natural veneer, depending on product configuration. Offers versatility for various end-use applications and finishing requirements.Flexible back finish available as either sanded core or natural veneer, depending on product configuration. Offers versatility for various end-use applications and finishing requirements.
- Back Color
- Natural wood colorUntreated natural hardwood back color showing the original grain pattern. Indicates no additional film, paint, or overlay coating is applied to the back surface.Untreated natural hardwood back color showing the original grain pattern. Indicates no additional film, paint, or overlay coating is applied to the back surface.
- Core Grade
- Mixed GradeCore veneers composed of mixed-grade hardwood plies. A cost-effective construction providing adequate structural performance for formwork and general industrial applications.Core veneers composed of mixed-grade hardwood plies. A cost-effective construction providing adequate structural performance for formwork and general industrial applications.
- Face
- Phenolic Surface Film - High-gsm Standard 165 gsmStandard-grade phenolic resin film at 165 g/m². Offers dependable moisture resistance and surface durability for mid-range formwork applications with 10–15 reuse cycles at a competitive price point.Standard-grade phenolic resin film at 165 g/m². Offers dependable moisture resistance and surface durability for mid-range formwork applications with 10–15 reuse cycles at a competitive price point.
- Face Color
- Dark BrownDeep brown face finish indicating phenolic film or high-density overlay treatment. The standard appearance for formwork and industrial-grade plywood panels.Deep brown face finish indicating phenolic film or high-density overlay treatment. The standard appearance for formwork and industrial-grade plywood panels.
- Glue
- WBP Melamine EcoEco-friendly Water Boil Proof melamine adhesive combining exterior-rated water resistance with reduced formaldehyde emissions. Suitable for formwork and exterior applications in markets requiring greener building materials.Eco-friendly Water Boil Proof melamine adhesive combining exterior-rated water resistance with reduced formaldehyde emissions. Suitable for formwork and exterior applications in markets requiring greener building materials.
- Maximum Repetition
- 3
- Moisture Content (%)
- 12
- Wood Species
- AcaciaAcacia mangium — fast-growing tropical plantation hardwood with density of 580–600 kg/m³. Offers good structural strength, natural durability, and excellent cost-effectiveness. Widely used for plywood cores across Southeast Asian manufacturing.Acacia mangium — fast-growing tropical plantation hardwood with density of 580–600 kg/m³. Offers good structural strength, natural durability, and excellent cost-effectiveness. Widely used for plywood cores across Southeast Asian manufacturing.EucalyptusEucalyptus plantation hardwood with high density (650–750 kg/m³), tight grain, and superior structural rigidity. Excellent dimensional stability and moisture resistance — the closest tropical species to Baltic Birch in performance characteristics.Eucalyptus plantation hardwood with high density (650–750 kg/m³), tight grain, and superior structural rigidity. Excellent dimensional stability and moisture resistance — the closest tropical species to Baltic Birch in performance characteristics.
Dimensions
- Cubic meter per piece
- 0.04
- Piece per Cubic Meter
- 22.4
- Piece per Square Meter
- 0.34
- Square Meter per Cubic meter
- 66.67
- Square meter per piece
- 2.98
- Thickness Tolerance (mm)
- According to EN315: +0.74 / -0.94
- Width & Length Tolerances (mm)
- 1mm per 1 meter
Mechanical Properties
- Bending Stiffness Across Grain (N/mm2)
- 2
- Bending Stiffness Along Grain (N/mm2)
- 2.5
- Bonding Strength (N/mm2)
- 1
- Mean Modulus of Elasticity (Across Grain) (N/mm2)
- 2500
- Mean Modulus of Elasticity (Along Grain) (N/mm2)
- 4500
- Min Bending Strength (Across Grain) (N/mm2)
- 25
- Min Bending Strength (Along Grain) (N/mm2)
- 40
- Shear Strength Across Grain (N/mm2)
- 1.5
- Shear Strength Along Grain (N/mm2)
- 1.7
Physical Properties
- Moisture Content (%)
- 12
- Thickness Swelling (%)
- 8
Chemical Properties
- Formaldehyde Emissions
- E2Formaldehyde emission class E2 (≤5.0 mg/L). Suitable for exterior, well-ventilated, or short-term applications such as construction formwork where panels are not used in enclosed living spaces.Formaldehyde emission class E2 (≤5.0 mg/L). Suitable for exterior, well-ventilated, or short-term applications such as construction formwork where panels are not used in enclosed living spaces.
- Applicable Certifications
- ISO9001 CertificationInternational quality management system standard. Certifies that manufacturing processes follow documented procedures for consistent product quality, continuous improvement, and customer satisfaction across all production batches.International quality management system standard. Certifies that manufacturing processes follow documented procedures for consistent product quality, continuous improvement, and customer satisfaction across all production batches.EN13986 CE MarkingEuropean harmonised standard EN 13986 for wood-based panels in construction. CE Marking certifies compliance with EU requirements for structural performance, formaldehyde emissions, and fire reaction under the Construction Products Regulation (CPR).European harmonised standard EN 13986 for wood-based panels in construction. CE Marking certifies compliance with EU requirements for structural performance, formaldehyde emissions, and fire reaction under the Construction Products Regulation (CPR).FSC COC CertificationForest Stewardship Council Chain of Custody certification. Verifies the wood originates from responsibly managed forests and is tracked through every stage of the supply chain from forest to final product, supporting sustainable forestry practices.Forest Stewardship Council Chain of Custody certification. Verifies the wood originates from responsibly managed forests and is tracked through every stage of the supply chain from forest to final product, supporting sustainable forestry practices.
Packaging
- One Bundle Loading Standard (Pieces)
- 60
- Product Packaging
- 9 image(s)
- Standard Bundle Height (mm)
- 1000
- Standard Bundle Length (mm)
- 2440
- Standard Bundle Weight (kg)
- 1527.1
- Standard Bundle Width (mm)
- 1220
Frequently Asked Questions
What is Single Form 2440x1220x15 mm used for?
Single Form 2440x1220x15 mm is a plywood product manufactured by Vinawood, suitable for film faced plywood applications. Contact our sales team for specific application guidance.
What are the dimensions of Single Form 2440x1220x15 mm?
Single Form 2440x1220x15 mm is available in 15mm T · 1220×2440 mm, weighing approximately 25.45 kg per sheet with a density of approximately 570 kg/m³.
What certifications does Single Form 2440x1220x15 mm have?
Vinawood maintains compliance with international standards including EPA TSCA Title VI (CARB P2), FSC Chain of Custody, CE marking, and EUDR traceability. Specific certification documents are provided with each shipment. Contact our team for the latest compliance details.
How can I order Single Form 2440x1220x15 mm?
You can request a quotation by contacting our sales team through the inquiry form on this page, or reach out directly via our contact page. We provide competitive FOB pricing, factory-direct from Vietnam.
Can I get samples of Single Form 2440x1220x15 mm?
Yes, Vinawood provides product samples upon request. Contact our sales team with your specifications and we will arrange sample delivery to help you evaluate the product before placing a bulk order.
