MDO 1SF Panel with Film backer - High Density - 2500x1250x18 mm
SKU: MDO3HDP25001250184.7 (3 reviews)
18mm T · 1250×2500 mm · ~35.44 kg/sheet · ρ ≈ 630 kg/m³
Introducing the MDO 1SF Panel with Film Backer - High Density - Purple Color by VINAWOOD, designed to meet the demands of heavy-duty formwork applications. This superior plywood features a high-density hardwood core made from Acacia, Eucalyptus, and Hevea wood species. The distinctive purple color MDO coating on one side and the top-grade 125gsm Phenolic Surface Film on the other provide enhanced durability and weather resistance. Experience unmatched strength, excellent moisture control, and a matte concrete surface without grain marks. Choose the MDO 1SF Panel with Film Backer - High Density - Purple Color for a robust and long-lasting construction solution.
Product family
MDO 1SF Panel with Film backer - High DensityVariants
MDO 1SF Panel with Film backer - High Density - 2440x1220x12 mmMDO 1SF Panel with Film backer - High Density - 2440x1220x15 mmMDO 1SF Panel with Film backer - High Density - 2440x1220x18 mmMDO 1SF Panel with Film backer - High Density - 2440x1220x21 mmMDO 1SF Panel with Film backer - High Density - 2500x1250x12 mmMDO 1SF Panel with Film backer - High Density - 2500x1250x15 mmMDO 1SF Panel with Film backer - High Density - 2500x1250x18 mmMDO 1SF Panel with Film backer - High Density - 2500x1250x21 mm
Specifications
Basic Specifications
- Grade
- AA GradePremium AA-grade panel with high-quality veneers throughout all layers. Minimal defects, uniform composition, and superior structural integrity for high-performance formwork and demanding construction applications.Premium AA-grade panel with high-quality veneers throughout all layers. Minimal defects, uniform composition, and superior structural integrity for high-performance formwork and demanding construction applications.
- Color
- Kraft Paper Color PurplePurple-tinted kraft paper overlay color. Specialized coloring for product differentiation and market-specific identification while maintaining standard MDO surface properties.Purple-tinted kraft paper overlay color. Specialized coloring for product differentiation and market-specific identification while maintaining standard MDO surface properties.
- Application
- FormworkConcrete forming and shuttering panels engineered to withstand repeated pours, chemical exposure, and high moisture on construction sites. Formwork plywood features overlay surfaces (phenolic, HDO, or MDO) for smooth concrete finishes and extended reuse life.Concrete forming and shuttering panels engineered to withstand repeated pours, chemical exposure, and high moisture on construction sites. Formwork plywood features overlay surfaces (phenolic, HDO, or MDO) for smooth concrete finishes and extended reuse life.
- Back
- Phenolic Surface Film - Top grade 125 gsmTop-quality 125 g/m² phenolic resin film on the back surface. Provides balanced moisture protection and dimensional stability to complement the face overlay, extending overall panel life in formwork applications.Top-quality 125 g/m² phenolic resin film on the back surface. Provides balanced moisture protection and dimensional stability to complement the face overlay, extending overall panel life in formwork applications.
- Back Color
- Dark BrownSolid dark brown back finish characteristic of phenolic resin-treated surfaces. Indicates good moisture resistance and chemical durability on the back panel.Solid dark brown back finish characteristic of phenolic resin-treated surfaces. Indicates good moisture resistance and chemical durability on the back panel.
- Core Grade
- AA GradeCore veneers all graded AA with minimal defects, tight joints, and uniform density. Delivers superior internal bonding strength and consistent panel performance under structural load.Core veneers all graded AA with minimal defects, tight joints, and uniform density. Delivers superior internal bonding strength and consistent panel performance under structural load.
- Face
- MDO 325 gsmMedium Density Overlay at 325 g/m² kraft paper surface. Provides a smooth, paintable matte finish suitable for concrete forming, signage, and exterior use with good durability at a lower cost than HDO overlays. Typically 10+ reuse cycles.Medium Density Overlay at 325 g/m² kraft paper surface. Provides a smooth, paintable matte finish suitable for concrete forming, signage, and exterior use with good durability at a lower cost than HDO overlays. Typically 10+ reuse cycles.
- Face Color
- Kraft Paper Color PurplePurple-tinted kraft paper overlay face. A specialized color for product differentiation and market-specific branding, maintaining the same smooth MDO surface properties as standard kraft overlays.Purple-tinted kraft paper overlay face. A specialized color for product differentiation and market-specific branding, maintaining the same smooth MDO surface properties as standard kraft overlays.
- Glue
- WBP PhenolicWater Boil Proof phenolic formaldehyde adhesive — the highest water-resistance glue standard. Withstands 72+ hours in boiling water without delamination. Required for marine, exterior, and heavy-duty formwork plywood.Water Boil Proof phenolic formaldehyde adhesive — the highest water-resistance glue standard. Withstands 72+ hours in boiling water without delamination. Required for marine, exterior, and heavy-duty formwork plywood.
- Maximum Repetition
- 17
- Moisture Content (%)
- 12
- Wood Species
- AcaciaAcacia mangium — fast-growing tropical plantation hardwood with density of 580–600 kg/m³. Offers good structural strength, natural durability, and excellent cost-effectiveness. Widely used for plywood cores across Southeast Asian manufacturing.Acacia mangium — fast-growing tropical plantation hardwood with density of 580–600 kg/m³. Offers good structural strength, natural durability, and excellent cost-effectiveness. Widely used for plywood cores across Southeast Asian manufacturing.EucalyptusEucalyptus plantation hardwood with high density (650–750 kg/m³), tight grain, and superior structural rigidity. Excellent dimensional stability and moisture resistance — the closest tropical species to Baltic Birch in performance characteristics.Eucalyptus plantation hardwood with high density (650–750 kg/m³), tight grain, and superior structural rigidity. Excellent dimensional stability and moisture resistance — the closest tropical species to Baltic Birch in performance characteristics.HeveaHevea brasiliensis (Rubberwood) — lightweight plantation hardwood with clean, light-colored grain. Primarily used for interior furniture components, decorative panels, and economy plywood cores where moderate strength and a uniform appearance are valued.Hevea brasiliensis (Rubberwood) — lightweight plantation hardwood with clean, light-colored grain. Primarily used for interior furniture components, decorative panels, and economy plywood cores where moderate strength and a uniform appearance are valued.
Dimensions
- Cubic meter per piece
- 0.06
- Piece per Cubic Meter
- 17.78
- Piece per Square Meter
- 0.32
- Square Meter per Cubic meter
- 55.56
- Square meter per piece
- 3.13
- Thickness Tolerance (mm)
- According to EN315: +0.74 / -0.94
- Width & Length Tolerances (mm)
- 1mm per 1 meter
Mechanical Properties
- Bending Stiffness Across Grain (N/mm2)
- 3
- Bending Stiffness Along Grain (N/mm2)
- 3.5
- Bonding Strength (N/mm2)
- 1
- Mean Modulus of Elasticity (Across Grain) (N/mm2)
- 6000
- Mean Modulus of Elasticity (Along Grain) (N/mm2)
- 7000
- Min Bending Strength (Across Grain) (N/mm2)
- 30
- Min Bending Strength (Along Grain) (N/mm2)
- 50
- Shear Strength Across Grain (N/mm2)
- 2
- Shear Strength Along Grain (N/mm2)
- 2.5
Physical Properties
- Moisture Content (%)
- 12
- Thickness Swelling (%)
- 8
Chemical Properties
- Formaldehyde Emissions
- E1Formaldehyde emission class E1 (≤1.5 mg/L). Low-emission standard widely accepted for indoor use in furniture, cabinetry, and residential construction across European, Asian, and most international markets.Formaldehyde emission class E1 (≤1.5 mg/L). Low-emission standard widely accepted for indoor use in furniture, cabinetry, and residential construction across European, Asian, and most international markets.
- Applicable Certifications
- ISO9001 CertificationInternational quality management system standard. Certifies that manufacturing processes follow documented procedures for consistent product quality, continuous improvement, and customer satisfaction across all production batches.International quality management system standard. Certifies that manufacturing processes follow documented procedures for consistent product quality, continuous improvement, and customer satisfaction across all production batches.EN13986 CE MarkingEuropean harmonised standard EN 13986 for wood-based panels in construction. CE Marking certifies compliance with EU requirements for structural performance, formaldehyde emissions, and fire reaction under the Construction Products Regulation (CPR).European harmonised standard EN 13986 for wood-based panels in construction. CE Marking certifies compliance with EU requirements for structural performance, formaldehyde emissions, and fire reaction under the Construction Products Regulation (CPR).FSC COC CertificationForest Stewardship Council Chain of Custody certification. Verifies the wood originates from responsibly managed forests and is tracked through every stage of the supply chain from forest to final product, supporting sustainable forestry practices.Forest Stewardship Council Chain of Custody certification. Verifies the wood originates from responsibly managed forests and is tracked through every stage of the supply chain from forest to final product, supporting sustainable forestry practices.
Packaging
- One Bundle Loading Standard (Pieces)
- 45
- Standard Bundle Height (mm)
- 910
- Standard Bundle Length (mm)
- 2500
- Standard Bundle Weight (kg)
- 1594.69
- Standard Bundle Width (mm)
- 1250
