Top Form Plus 2440x1220x18 mm
SKU: FFP06PL2440122018
18mm T · 1220×2440 mm · ~34.83 kg/sheet · ρ ≈ 650 kg/m³
Product family
Top Form PlusSpecifications
Basic Specifications
- Grade
AA-grade panel constructed from full-size veneer sheets without joints, scarf splices, or finger-jointing. Provides maximum structural integrity and uniform load-bearing performance across the entire panel area.
- Color
Deep brown coloring characteristic of phenolic resin-treated or film-faced surfaces on formwork and industrial plywood panels.
- Application
Concrete forming and shuttering panels engineered to withstand repeated pours, chemical exposure, and high moisture on construction sites. Formwork plywood features overlay surfaces (phenolic, HDO, or MDO) for smooth concrete finishes and extended reuse life.
- Back
Premium 220 g/m² phenolic resin film on the back surface — the heaviest-grade back overlay. Provides maximum moisture barrier and dimensional stability for heavy-duty formwork requiring equal protection on both panel faces.
- Back Color
Solid dark brown back finish characteristic of phenolic resin-treated surfaces. Indicates good moisture resistance and chemical durability on the back panel.
- Core Grade
AA-grade core constructed from full-size veneer sheets without joints or splices. Eliminates potential weak points from finger-jointing, providing the most consistent structural performance.
- Face
Premium phenolic resin film at 220 g/m² — the heaviest film-faced specification. Delivers maximum overlay durability, moisture barrier performance, and 15–20+ reuse cycles for heavy-duty concrete formwork and infrastructure projects.
- Face Color
Deep brown face finish indicating phenolic film or high-density overlay treatment. The standard appearance for formwork and industrial-grade plywood panels.
- Glue
Water Boil Proof phenolic formaldehyde adhesive — the highest water-resistance glue standard. Withstands 72+ hours in boiling water without delamination. Required for marine, exterior, and heavy-duty formwork plywood.
- Maximum Repetition
- 50
- Moisture Content (%)
- 12
- Wood Species
Acacia mangium — fast-growing tropical plantation hardwood with density of 580–600 kg/m³. Offers good structural strength, natural durability, and excellent cost-effectiveness. Widely used for plywood cores across Southeast Asian manufacturing.; Eucalyptus plantation hardwood with high density (650–750 kg/m³), tight grain, and superior structural rigidity. Excellent dimensional stability and moisture resistance — the closest tropical species to Baltic Birch in performance characteristics.; Hevea brasiliensis (Rubberwood) — lightweight plantation hardwood with clean, light-colored grain. Primarily used for interior furniture components, decorative panels, and economy plywood cores where moderate strength and a uniform appearance are valued.
Dimensions
- Cubic meter per piece
- 0.05
- Piece per Cubic Meter
- 18.66
- Piece per Square Meter
- 0.34
- Square Meter per Cubic meter
- 55.56
- Square meter per piece
- 2.98
- Thickness Tolerance (mm)
- According to EN315: +0.74 / -0.94
- Width & Length Tolerances (mm)
- 1mm per 1 meter
Properties
Mechanical Properties
- Bending Stiffness Across Grain (N/mm2)
- 2.8
- Bending Stiffness Along Grain (N/mm2)
- 3.3
- Bonding Strength (N/mm2)
- 1
- Mean Modulus of Elasticity (Across Grain) (N/mm2)
- 3700
- Mean Modulus of Elasticity (Along Grain) (N/mm2)
- 6200
- Min Bending Strength (Across Grain) (N/mm2)
- 35
- Min Bending Strength (Along Grain) (N/mm2)
- 50
- Shear Strength Across Grain (N/mm2)
- 2.4
- Shear Strength Along Grain (N/mm2)
- 2.6
Physical Properties
- Moisture Content (%)
- 12
- Thickness Swelling (%)
- 8
Chemical Properties
- Formaldehyde Emissions
Formaldehyde emission class E1 (≤1.5 mg/L). Low-emission standard widely accepted for indoor use in furniture, cabinetry, and residential construction across European, Asian, and most international markets.
Compliance
- Applicable Certifications
International quality management system standard. Certifies that manufacturing processes follow documented procedures for consistent product quality, continuous improvement, and customer satisfaction across all production batches.; European harmonised standard EN 13986 for wood-based panels in construction. CE Marking certifies compliance with EU requirements for structural performance, formaldehyde emissions, and fire reaction under the Construction Products Regulation (CPR).; Forest Stewardship Council Chain of Custody certification. Verifies the wood originates from responsibly managed forests and is tracked through every stage of the supply chain from forest to final product, supporting sustainable forestry practices.
Logistics
Packaging
- One Bundle Loading Standard (Pieces)
- 45
- Product Packaging
- 9 image(s)
- Standard Bundle Height (mm)
- 910
- Standard Bundle Length (mm)
- 2440
- Standard Bundle Weight (kg)
- 1567.29
- Standard Bundle Width (mm)
- 1220
