VINAWOOD Film Faced Plywood is tested and certified by the Vietnam Institute for Building Materials (VIBM) – Ministry of Construction (MOC). Below is the test result:VIBM

TEST RESULT

NoPropertyUnitResultTest method
 1 Humidity % 10,9 TCVN 7756-3:2007
 2 Density kg/m3 636,0 TCVN 7756-4:2007
 3 Swelling in thickness after 24 hours immersion in water % 1,8 TCVN 7756-5:2007
 4 Bending srength MPa 45,4 TCVN 7756-6:2007
 5 Modulus of elasticity in bending MPa 6335,0 TCVN 7756-6:2007
 6 Bonding quality MPa 1,90 TCVN 7756-9:2007
 7 The force of holding screws (Surface) N 1621 TCVN 7756-11:2007
 8The force of holding screws (Edge) N 1069 TCVN 7756-11:2007

Tested on July 28, 2015 by VIBM.
